Separation
Hurrikan S
Wind sifter with electric drive
Electric
Mobile
Mechanical driveThe Hurrikan S wind sifter provides effective removal of plastic film from screen overflow. It works with a patented pressure-suction process that gives the Hurrikan S a separation efficiency of up to 95 percent.
Electric drive of all components ensures top efficiency while offering many control possibilities. Magnetic and roller separators can further enhance the quality of the recyclable output.
- 10
Weight (t)
- 60
Throughput (m³/h)
- 55
Engine Power (kW)
Flexible
applicable
The standard design of the windsifter is a central axle trailer (tandem axle on the S version). A power unit, available as an accessory, lends the windsifter complete independence from the power supply. The wide feed chute allows operation in conjunction with feed conveyor belt width to 1200mm and feed height of 1950mm to 2250mm.
High suction
performance
A radial fan is used to generate a flow of compressed air. The suction/conveying fan has a specially designed rotor that guarantees smooth throughput. The fan is foldable upwards for servicing work, on request a servicing platform makes access easy. The suction performance is adjustable to material by variation of fan speed, fan distance and vent flaps.
Efficient
separation
The pressure-suction system gives extremely effective removal of light materials from screen overflow. First, the pressure blower separates the material. Light materials settle onto the remaining fraction. In a second step, the light materials are pulled away by a suction blower. Magnetic and roller separators can further enhance the quality of the output.
Options
Fe-separation is done by a powerful permanent magnet of the discharge conveyor. By a rolling fraction separator – a tiltable conveyor belt – round, heavy objects (mainly stones) roll downwards and are diverted via a chute.
- Hurrikan S
- Perkins
Producer
- 55/74
Power (kW/hp)
- 80
Power (kvA)
- 10
Weight (tonnes)
- up to 60
Throughput capacity (m³/h)
- 1600
Feed width (mm)
- 1950 - 2250
Feed height (mm)
- 2600
Abwurfhöhe (mm)
- 7,5
Centrifugal blower (kW) (compressed air flow)
- 2 x 15
Suction fan (kW) (suction and delivery flow)
*depending on equipment
